A2A Sample: Travel Planner OpenRouter

This is a Python implementation that adheres to the A2A (Agent2Agent) protocol. A travel assistant demo implemented based on Google's official a2a-python SDK and OpenAI Python SDK. It is a travel assistant in line with the specifications of the OpenAI model, capable of providing you with travel planning services.

Source Code

A2A Travel Planner OpenRouter

Project Architecture

This project demonstrates how to build an interoperable travel planning agent using the A2A protocol, including the following core components:

• Travel Planner Agent: Core travel assistant logic based on OpenAI-compatible interface
• Agent Executor: A2A protocol adapter that bridges agent logic to A2A server
• A2A Server: A2A protocol-compliant server providing standardized inter-agent communication interface
• Loop Client: Test client for interacting with the A2A server

Workflow Sequence Diagram

sequenceDiagram
    participant Client
    participant A2AServer
    participant RequestHandler
    participant Executor as TravelPlannerAgentExecutor
    participant Agent as TravelPlannerAgent
    participant LLM as OpenAI-Compatible LLM

    Client->>A2AServer: Request Agent Card
    A2AServer->>Client: Return Agent Card (skills, capabilities)

    Note over Client,A2AServer: User queries travel planning

    Client->>A2AServer: message/sendStream (streaming request)
    A2AServer->>RequestHandler: Route streaming request
    RequestHandler->>Executor: execute(context, event_queue)

    Executor->>Agent: stream(query)
    Agent->>LLM: chat.completions.create(stream=True)

    loop Streaming response processing
        LLM-->>Agent: Return streaming content chunk
        Agent-->>Executor: yield {'content': chunk, 'done': False}
        Executor-->>RequestHandler: TaskArtifactUpdateEvent
        RequestHandler-->>A2AServer: Push SSE event
        A2AServer-->>Client: Stream content update
    end

    LLM-->>Agent: Final response completed
    Agent-->>Executor: yield {'content': '', 'done': True}
    Executor-->>RequestHandler: Final TaskArtifactUpdateEvent
    RequestHandler-->>A2AServer: Final SSE event
    A2AServer-->>Client: Streaming response completed

Main Workflow

1. Agent Card Retrieval: Client first retrieves agent card from A2A server to understand agent capabilities and skills
2. Streaming Request Processing: Client sends streaming message request with user query
3. Agent Execution: Agent executor processes the request and calls travel planner agent core logic
4. LLM Interaction: Agent conducts streaming conversation with OpenAI-compatible LLM
5. Real-time Response: Stream responses to client in real-time via Server-Sent Events (SSE)

Getting started

1. Configure environment variables:

Copy the example file and configure your API credentials.

cp env.example .env

Edit .env file with your actual values:

# Required: Your API key for the AI model service
API_KEY=your_actual_api_key_here

# Optional: Model name (default: google/gemini-2.0-flash-001)
MODEL_NAME=google/gemini-2.0-flash-001

# Optional: Base URL for the API service
BASE_URL=https://openrouter.ai/api/v1

2. Install dependencies and start the server:

   uv venv
   source .venv/bin/activate

   uv sync
   uv run .


3. Run the loop client in a new terminal:

   source .venv/bin/activate
   uv run loop_client.py


Configuration

The application uses environment variables for configuration:

• API_KEY (required): Your API key for the AI model service
• MODEL_NAME (optional): The model name to use (default: "google/gemini-2.0-flash-001")
• BASE_URL (optional): The base URL for the API service (default: "https://openrouter.ai/api/v1")

Technical Features

Current Implementation

• ✅ A2A Protocol Compliance: Fully compliant with Agent2Agent protocol specification
• ✅ Streaming Response: Supports real-time streaming content generation
• ✅ OpenAI Compatible: Supports any OpenAI-compatible API interface
• ✅ Modular Design: Clear separation between agent logic and protocol adaptation
• ✅ Environment Configuration: Flexible environment variable configuration

Future Enhancement Plans

Task State Management Enhancement

Based on Google A2A LangGraph sample, planning to add the following features:

• 🔄 Task Lifecycle Management: Implement complete task state tracking (submitted → working → completed/failed)
• 🔄 Multi-turn Conversation Support: Add input_required state to support complex travel planning scenarios requiring user clarification
• 🔄 Task Persistence: Implement task state persistence for long-running planning tasks
• 🔄 Enhanced Error Handling: More detailed error states and recovery mechanisms
• 🔄 Task Cancellation: Support cancellation of ongoing tasks

State Management Example

# Future state management implementation example
class TravelPlannerTaskManager:
    async def handle_complex_query(self, query: str, context: RequestContext):
        # Detect if more information is needed
        if self.needs_clarification(query):
            return TaskStatus(
                state=TaskState.input_required,
                message="More information needed: Please provide specific destination, dates, and budget range"
            )

        # Execute complex multi-step planning
        task_id = await self.create_long_running_task(query)
        return TaskStatus(
            state=TaskState.working,
            taskId=task_id,
            message="Creating detailed travel plan..."
        )

Planned Feature Additions

• 📋 Structured Data Support: Add DataPart support for form-based travel preference collection
• 🖼️ Multimedia Support: Support FilePart for generating and processing travel images, maps, etc.
• 🔍 Tool Integration: Integrate external APIs (weather, flights, hotels, etc.) as tool calls
• 🌐 Multi-language Support: Extend multi-language travel planning capabilities
• 📊 Analytics Metrics: Add collection of task execution time, success rate metrics
