A2A Python Sample: Github Agent

An intelligent GitHub agent built with A2A (Agent2Agent) SDK that can query GitHub repositories, recent updates, commits, and project activity using natural language.

🏗️ Architecture

This project implements an A2A Server that uses an OpenAI-based agent with GitHub API integration. The architecture consists of the following key components:

Component Overview

• A2A Server (__main__.py): The main server application that handles HTTP requests and manages agent lifecycle
• OpenAI Agent Executor (openai_agent_executor.py): Executes agent tasks with OpenRouter API integration
• GitHub Toolset (github_toolset.py): Provides GitHub API tools for repository operations
• Agent Definition (openai_agent.py): Defines the agent's capabilities and system prompt

Architecture Flow

sequenceDiagram
    participant Client as A2A Client
    participant Server as A2A Server
    participant Agent as OpenAI Agent
    participant GitHub as GitHub API
    participant OpenRouter as OpenRouter API

    Note over Client,OpenRouter: A2A GitHub Agent Architecture

    Client->>Server: HTTP Request<br/>(query about GitHub)
    Server->>Agent: Process Request<br/>(OpenAIAgentExecutor)

    Agent->>OpenRouter: Send Chat Completion<br/>(with tools defined)
    OpenRouter-->>Agent: Response with tool calls

    loop Tool Execution
        Agent->>GitHub: API Call<br/>(GitHubToolset)
        GitHub-->>Agent: Repository/Commit Data
        Agent->>OpenRouter: Send tool results
        OpenRouter-->>Agent: Final response
    end

    Agent->>Server: Streaming Response<br/>(TaskUpdater)
    Server->>Client: HTTP Response<br/>(formatted results)

    Note over Client: User sees GitHub data<br/>formatted by AI

🔧 Key Modules Logic

1. Main Server (__main__.py)

• Initializes the A2A server with Starlette framework
• Creates an AgentCard that defines the agent's capabilities and skills
• Sets up the OpenAI agent executor with GitHub tools
• Starts the HTTP server on the specified host and port

2. GitHub Toolset (github_toolset.py)

Provides three main GitHub API functions:

• get_user_repositories(): Retrieves recent repositories for a user
• get_recent_commits(): Fetches recent commits for a specific repository
• search_repositories(): Searches for repositories with recent activity

All functions include error handling and support optional parameters for filtering.

3. OpenAI Agent Executor (openai_agent_executor.py)

• Manages the conversation flow with OpenRouter API
• Converts GitHub tools to OpenAI function calling format
• Handles tool execution and response streaming
• Implements iterative conversation with tool calls

4. Agent Definition (openai_agent.py)

• Creates the agent with system prompt and available tools
• Defines the agent's behavior for GitHub-related queries
• Configures the agent to provide helpful repository information

📋 Prerequisites

• Python 3.10 or higher
• UV - Python package manager
• OpenRouter API Key - For AI capabilities
• GitHub Personal Access Token (optional, but recommended for higher rate limits)

🚀 Step-by-Step Setup and Running

Step 1: Clone and Setup Environment

# Clone the repository
git clone https://github.com/sing1ee/a2a-py-github-agent.git
cd a2a-py-github-agent

# Create virtual environment
uv venv
source .venv/bin/activate  # On Windows: .venv\Scripts\activate

Step 2: Install Dependencies

# Install dependencies using UV
uv sync

Step 3: Configure Environment Variables

Create a .env file in the project root:

# OpenRouter API Key (required)
echo "OPENROUTER_API_KEY=your_openrouter_api_key_here" > .env

# GitHub Personal Access Token (optional but recommended)
echo "GITHUB_TOKEN=your_github_personal_access_token_here" >> .env

Note: The GitHub token is optional. Without it, the agent will use unauthenticated access with limited rate limits (60 requests per hour vs 5000 with token).

Step 4: Run the A2A Server

# Activate virtual environment
source .venv/bin/activate

# Run the server
uv run .

The server will start on http://localhost:10007 by default.

🧪 Client Testing

Option 1: Using A2A Movie Agent Client

You can test the GitHub agent using the A2A Movie Agent client:

# Clone the A2A Movie Agent client
git clone https://github.com/sing1ee/a2a-js-movie-agent.git
cd a2a-js-movie-agent

# Install dependencies
bun install

# Connect to your GitHub agent
bun cli http://localhost:10007

This will start an interactive CLI that connects to your GitHub agent server.

Option 2: Using Direct HTTP Requests

You can also test using curl or any HTTP client:

# Example: Test with a simple query
curl -X POST http://localhost:10007/ \
  -H "Content-Type: application/json" \
  -d '{
  "jsonrpc": "2.0",
  "id": 1,
  "method": "message/send",
  "params": {
    "message": {
      "role": "user",
      "parts": [
        {
          "kind": "text",
          "text": "Show recent commits for repository 'facebook/react'"
        }
      ],
      "messageId": "9229e770-767c-417b-a0b0-f0741243c589"
    },
    "metadata": {}
  }
}'

💡 Example Queries

The GitHub Agent can handle queries like:

• Recent Commits: "Show recent commits for repository 'facebook/react'"
• Repository Search: "Search for popular Python repositories with recent activity"
• Project Activity: "What are the latest updates in machine learning repositories?"

🔑 GitHub Token Setup

To create a GitHub Personal Access Token for better rate limits:

1. Go to GitHub Settings > Tokens
2. Click "Generate new token (classic)"
3. Select the following scopes:
   • repo - Access to repositories
   • user - Access to user information
4. Copy the token and add it to your .env file

🛠️ Configuration Options

Server Configuration

You can customize the server using command-line options:

# Custom host and port
uv run . --host=0.0.0.0 --port=10007

Environment Variables

• OPENROUTER_API_KEY: Your OpenRouter API key (required)
• GITHUB_TOKEN: GitHub Personal Access Token (optional)

📖 API Documentation

Available Tools

1. get_user_repositories

   • Get user's repositories with recent updates
   • Parameters: username (optional), days (default: 30), limit (default: 10)

2. get_recent_commits

   • Get recent commits for a repository
   • Parameters: repo_name (required), days (default: 7), limit (default: 10)

3. search_repositories

   • Search for repositories with recent activity
   • Parameters: query (required), sort (default: 'updated'), limit (default: 10)

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

🔗 Related Projects

• A2A SDK - The underlying A2A protocol implementation
• A2A Movie Agent - A movie information agent built with A2A protocol
